1 To 8 Port High Resolution/High Quality Video Splitter (VGA-108A)
- Support ULTRA HIGHT 350MHz Video Bandwidth.
- Built-in Video Signal Enhancement Enhance Video Signals For Distance up to 65m (213")
- Daisy Chain Enabled.
- Supports DDC, DDC2, DDC2B at Port 1.
- Supports 1920x1440@60Hz
| Input Connectors HDB - 15 Female |
1 |
1 |
1 |
| Output Connectors HDB-15 Female |
2 |
4 |
8 |
| Output Impedance/Level |
RGB: 75 , 0.7Vp-p ; HV SYNC: TTL Level. |
| Bandwidth (-3db) |
350MHz |
| Resolution |
1920x1440, Support DDC, DDC2, DDC2B (at PNP Port) |
| Horizontal |
30~180KHz |
| Vertical |
43-250Hz |
| Transfers Distance |
<50 Meters |
| Power Consumption |
Use AC-DC Adaptor DC 9-12V, Consumption: |
| <0.9W |
<1.7W |
<3.3W |
| Dimensions (LXWXH) |
110x56x25mm |
| Housing |
Metal |
| Operating Temperature |
5~40°C |
| Humidity |
0~80°C |
High Resolution VGA Splitters are Particularly Designed For Distributing And Displaying The Signals Of The Computer High Resolution RGB Images. The Products are widely used for Large screen projection system, electrochemistry, commanding and controlling system, multi-media conference room, ticket office, etc. By using our HR series high resolution VGA splitters, one input to chaining output, or chain input to chain output, or chain input to chain output could be easily done. Users can display and switch the signals easily during the demonstration. The 250MHz bandwidth can handle all kinds of VGA signals.
You can choose USB cable or external power supply for the Splitter.
 |
