Operating
:
A. ON/OFF: Press on/off button for 2
seconds
to start the device. It gets into the video standby mode (BLUE LED).
Meanwhile
the blue light indicator is on.
b.
Record
video:
In the video standby mode , short
press ON/OFF Buttom, the blue light flashes 3 times and now it
is recording (no light).. To stop the recording, short press ON/OFF
button twice, the recording will stop and saved. Now LED in blue
standby mode. Press the ON / OFF
for 3 second.. red LED will blink 3 times will OFF the device.
c.
Take
photo: In the video standby mode, Press the switch mode
button for once. The RED LED Ligth up, now in photo standby mode.
To take photo, short press ON/Off Button once, it will take one photo
(RED LED Blink once). Press again to take again.
Note: Make sure there is adequate light in the surrounding and the
camera is not blocked by other items. Keep the camera upright and
stable. And the object should be more than 50cm from the camera.
e: AV Playback on TV:
Connect AV cable to TV AV, press ON/Off button 2 second (now in Blue
LED light up / standby mode). Press mode switch twice (LED RED and BLUE
light up together), now in AV playback standby mode. Press ON/Off
button once to start playback. press again to stop . To play next
files, long press mode switch to play next files. Short press switch
mode to jump out from AV playback mode.
f. PC camera: Plug the watch with USB cable to computer
(computer detect the flash drive). Now Press ON/OFF button, The watch
will change to PC camera mode (driver installation started for the
first time use). In this mode,
your camera can be used as a PC camera, with your friends online video
chat, take photos, and so on.
Note: According to the computer system configuration or difference, the
computer may not detect a camera function by once, if the computer can
not enter the camera function, but into a Udisk. Please remove the
camera and connect the camera to the computer again; If you are the
first time to use the PC camera function on your computer, please
install the drivers on the CD or dealers provided. Please connect the
data cable to the device at first, then connect the other side to the
Computer.
g.Connect the computer: In standby or OFF
mode, you can connect the device with the computer. The computer will
pop up a removable disk logo. There is an image file directory for: *
Disk \ _REC \ 100MEDIA. During video recorder and computer transfer
data, the blue light flashes rapidly. For the disconnection, please
click ‘SAFELY REMOVE HARDWARE’ on the right bottom corner of the task
bar. Then click to stop the ‘USB mass storage device’. Unplug the USB.
The disconnection completes.
Note: According to the computer or system configuration, there will be
slight difference for the time of identifying removable disk. Please be
patient. During this period, please do not press the button to avoid
the bad impact of computer hardware. If the computer does not identify
the removable disk long time, disconnect and reconnect the device. If
the computer is unable to identify the hardware yet, make sure your
operating system, driver and USB cable are all in normal condition.
Please make sure to disconnect the device in accordance with the normal
process to avoid the possible damage for computer and recorder.
h.Charge: Connect to computer USB
interface or charger. During the charging, the red light flashes
slowly. When the battery is fully recharged, there is no light.
Note:
The recorder is with built-in high-capacity lithium polymer
battery. The battery is with no memory effect. It can be used and
charged at anytime. But for the initial five times of charging, please
charge battery to saturation after the battery runs out. It is to
activate the battery maximum capacity and maintain the standard working
time.
h. Change Time: To
set the time on the photo/video, just open a text file (notepad), Type
time according this format: 2011-09-21 18:00:36 in the notepad and save
as time.txt in watch memory (root directory / most outside). Then plug
out the USB. Now time is set.
FAQ - Frequently Asked Questions
- How can I reset the watch?
Press the ON/OFF key and Photo/Sound key at the same time.
