Gigabyte GA-M61SME-SE AMD Socket AM2 Nforce 6100 Motherboard

 Condition : New         Item at : SS2, Subang Jaya, OUG / Selangor

 Main > Computer & Software > Hardware > Mother Board > For AMD
Sale Price / Unit : RM 185.00 (Firm)
Shipping Fee : Peninsular           : RM 10
Sabah, Labuan    : RM 15
Sarawak               : RM 15
Shipping Method :  POS Laju, Self Collect, Parcel Services
Ship To : Within Malaysia
Payment Method :  Maybank 2U, MicroPay, Cash on Collection (COC), Bank Transfer / TT / Wire, SafeTrade , Others :, RHB, Public
Time Left :
days   hrs   mins   secs
11 Feb 2008 12:47:00 AM ~ 17 Mar 2008 12:47:00 AM
Brand : Gigabyte - S Series
Model / SKU / Code :
Available Qty : 50
View / WatchList : 136 times / 1 times
Note : The seller assumes all responsibility for listing this item. Please contact the seller to resolve any questions before or after purchasing the item. Currency is RM (Ringgit Malaysia) unless otherwise noted.

Seller ID : yahoong

Rating :  (2375: 165+,100%)
Status : Active
Member Since : 8 Jul 2004
E-Mail Seller
Favourite Seller [967]
Ask Question (0)

  • Safeguard your online purchase
  • From as low as RM2 / trade
  • Remove Fear from Fraud and Dispute
Product Description



Feature available to Store Members

GIGABYTE AMD SOCKET AM2 MOTHERBOARD GA-M61SME-S2 ~

New Design With Outstanding Features And Performance.

- Built In USB 2.0 ,LAN , RAID . Sound & Graphic

- Support AM2 Athlon/ Sempron 64 Bits Processor

- Nforce 6100 Chipset



Overview

  1. Supports AMD AM2+ Phenom*/ AM2 Athlon 64 series processors
  2. Supports high performance Dual Channel DDR2 800 memory
  3. Integrated NVIDIA® CineFX 3.0 Graphics Engine
  4. Features NVIDIA® SATA 3Gb/s with RAID function
  5. Integrated 10/100 Ethernet solution
  6. Enhances security with NVIDIA TCP/IP Acceleration technology
  7. Features 8 channel High Definition Audio
  8. RoHS compliant motherboard for green computing
  9. Supports Windows Vista Premium


Specifications
CPU
  1. Support for Socket AM2+/ AM2 processors: AMD Phenom™FX processor/ AMD Phenom™ processor/ AMD Athlon™ 64 FX processor/AMD Athlon™ 64 X2 Dual-Core processor/AMD Athlon™ 64 processor/AMD Sempron™ processor.
(Note) If you install AMD AM2+ CPU on AM2 motherbord, the system bus speed will downgrade from HT3.0(5200MHz) to HT1.0(2000 MT/s) spec; however, the frequency of AM2+ CPU will not be impacted. Please refer "CPU Support List" for more information.
Chipset
  1. NVIDIA® GeForce 6100 / nForce 405 chipset
  2. Super I/O: ITE IT8716 chip
  3. Integrated Peripherals
    1. Realtek RTL8201 phy
    2. Realtek ALC883 Audio Codec
Memory
  1. 2 DDR2 DIMM memory slots (supports up to 8GB memory)(Note 1)
  2. Supports dual channel DDR2 800/667/533/400 DIMMs
  3. Supports 1.8V DDR2 DIMMs
(Note 1) Due to the limitation of Windows 32-bit operating system, when more than 4GB of physical memory is installed, the actual memory available for the operating system will be less than 4GB; Windows 64-bit operating system doesn't have such limitation.
Internal I/O Connectors
  1. 1 24-pin ATX power connector
  2. 1 4-pin ATX 12V power connector
  3. 1 floppy connector
  4. 1 IDE connectors
  5. 2 SATA 3Gb/s connectors
  6. 1 CPU fan connector
  7. 1 system fan connector
  8. 1 front panel connector
  9. 1 front audio connector
  10. 1 CD In connector
  11. 1 COMB connector
  12. 1 Power LED connector
  13. 2 USB 2.0/1.1 connectors for additional 4 USB 2.0/1.1 ports by cables
  14. 1 SPDIF In/Out connector
  15. 1 Chassis Intrusion connector
  16. 1 HDA_SUR connector
Expansion Slots
  1. 1 PCI Express x 16 slot (Note 2)
  2. 1 PCI Express x 1 slot
  3. 2 PCI slots
(Note 2) The GA-M61SME-S2 supports up to PCI Express x8 mode. (please refer to the VGA cards support list)
Back Panel Connectors
  1. 1 PS/2 keyboard port
  2. 1 PS/2 mouse port
  3. 1 parallel port
  4. 1 COMA port
  5. 1 VGA port
  6. 4 USB 2.0/1.1 ports
  7. 1 RJ-45 port
  8. 3 audio jacks (Line In / Line Out / MIC In)
Power ATX power connector and ATX 12V connector
Form Factor Micro ATX form factor; 24.4cm x 22.5cm
H/W Monitoring
  1. System voltage detection
  2. CPU / System temperature detection
  3. CPU / System fan speed detection
  4. CPU / System warning temperature
  5. CPU / System fan failure warning
  6. Supports CPU Smart Fan function(Note3)
(Note 3) Whether the CPU Smart FAN Control function is supported will depend on the CPU you install.
BIOS
  1. 1 4Mbit flash ROM
  2. Use of licensed AWARD BIOS
  3. PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b
Other Features
  1. Supports @BIOS
  2. Supports Download Center
  3. Supports Q-Flash
  4. Supports EasyTune(Note 4)
  5. Supports Xpress Install
  6. Supports Xpress Recovery2
  7. Supports Xpress BIOS Rescue
(Note 4) EasyTune functions may vary depending on different motherboards.
Remark
  1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
  2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website



What's included:

  • Gigabyte Motherboard Retail Pack
