LATEST OFFER!!! New version of the famous i-Blue 737 with new 51 channels MTK Chipset.

Introduction Price at RM280 with FREE SHIPPING within Malaysia.

Our GPS Receiver has been certified by SIRIM for distribution in Malaysia.

I-Blue737 51 CH Bluetooth GPS receiver

-Blue737 Bluetooth GPS receiver provides you with best accuracy and highest sensitivity. i-Blue737 is a 51-Channel Bluetooth GPS Receiver with -158dBm high sensitivity and has up to 25 hours of navigation time. It builded with a super-sensitive MTK chipset(New Version) that rivals the sensitivity of the SirfIII chipset. iBlue 737 supports fuzzy auto on/off. It can automatically enter the sleeping mode after your turning off the Bluetooth connectivity, thus you can always power it on with very low power consumption. With fuzzy auto on/off, if the connection between your device and iBlue 737 is successful, it will wake up itself and the blue LED of iBlue 737 will be quickly blinking again (every 2 sec) and the orange LED of iBlue 737 will also be on.



Key Advantages

Great Performance - i-Blue 737 Bluetooth GPS receiver is equipped with the new 51 channel MTK chipset which offers ultra high sensitivity at -158dBm (tracking) and lower power consumption at 42mA.



Auto On/Off - When you use i-Blue 737 for the first time, just power up and place the receiver under the windshield in car. Anytime when a paired PDA or laptop computer with Bluetooth connectivity is onboard, i-Blue will wake up on Bluetooth for your navigating usage. When Bluetooth signal is not present, i-Blue will go into sleeping mode automatically (Slow blinking blue LED).



Best Accuracy - i-Blue 737 supports DGPS (WAAS, EGNOS, MSAS) for great accuracy at 2.5m





Read the reviews from professional and other forums to believe it.



AXIMSITE FORUM - The receiver works as advertised, with long battery life and a novel sleep mode that saves power

POCKET PC REVIEW FORUM - Great Battery Life and Super Sensitive

GPS PASSION FORUM - Bluetooth : auto-off/on - MTK Chipset : GPS power of SiRFstarIII, 50% power use

 MTEKK FORUM - Serious competition for SiRF111 chipsets - very serious











WHAT'S HOT

The key attributes of the i-Blue 737 are:

51-Channel all-in-view satellite tracking

Ultra high sensitivity MTK chipset (-158dBm)

Smart power saving function for up to 25 hours of operation on one charge

Smart auto sleep & wake function for up to 360 hours in standby mode

Compatible with Nokia Phone battery

Fast position acquisition, 36 seconds from a cold start, 33 seconds from a warm start, and 1 second from a hot start.
Compatible with WAAS, EGNOS, and MSAS accuracy augmentation signals

Position accuracy within 3 meters without augmentation signal

Position accuracy within 2.5 meters with WAAS, EGNOS, or MSAS augmentation signal

Support for the NMEA-0183 V3.0 GPS communication standard V3.0 (4800-115200 baud)

Support for the Bluetooth version 1.1, 1.2 and 2.0 Serial Protocol Profile (SPP)

RoHS Compliant



The package includes :

 - Bluetooth GPS Receiver – iBlue 737 51CH -GPS x 1

 - Traveler Power Adapter(Malaysia type 3 Pin) x 1

 - DC cigarette lighter adapter x 1

 - Lithium rechargeable battery x 1

 - User's manual with Warranty Card x 1

-  Navigation Software and Map CD

 Warranty

-         1 year warranty on the device and 6 months on the battery



 Product Specification:

Antenna

Receiver Frequency: 1575.42 MHz (L1 band) C/A code

Antenna Type: Built-in Active Antenna

GPS Receiver

Technology: MTK MT3301 + MT3179

Satellite Measure Used: 51

Tracking Sensitivity: -158 dBm

Battery Life: 25 hours with built-in rechargeable battery.

Bluetooth

Standard: Bluetooth V1.2

Profile: Serial Port Profile (SPP)

Range: Up to 15 meters

Time to First Fix (TTFF)

Reacquisition: 0.1 second typical

Warm Start: 36 seconds typical

Cold Start: 39 seconds typical

Accuracy of Position Fix

Horizontal: Without aid: 3.0m 2D-RMS; <3m CEP(50%) without SA(horizontal); DGPS (WAAS, EGNOS, MSAS):2.5m

Velocity: Without aid: 0.1m/s; DGPS (WAAS, EGNOS, MSAS,RTCM): 0.05m/s

Receiver Configuration

Baud Rate: 4800/9600/14400/19200/38400/57600/115200 bps

Output Message: NMEA 0183 v3.01(Default: GGA, GSA, GSV, RMC

Physical Characteristics

Dimension: 72.2 x 46.5 x 20mm

Weight: 64.7g





Recommanded GPS Software and Maps for Malaysia and Singapore

1)Garmin Que (Pocket PC) with Maps from http://www.malsingmaps.com/  has the most frequent updated maps of Malaysia and Singapore. It is free!!! please pay a visit to their site http://www.malsingmaps.com/  for more information about GPS and Maps.

2)MAPKING (Pocket PC, Notebook and Smartphone) has the reasonably accurate maps for Asia including Malaysia. It has a nice 3D Navigating interface, please logon to their website http://www2.mapking.com/en/default.htm for a trial version to experience the 3D nevigation.

3)iMAP (Pocket PC) a 99% similar to the Mapking with the maps updated and polished up. http://www.navitech.com.my/





Specifications:

Category	Parameter	Description
General	Chipset	MTK GPS
	Frequency	L1,1575.42 MHZ
	C/A Code	1.023 MHZ
	Channels	51
	DGPS	WAAS, EGNOS, MSAS
	Datum	WGS84
	CPU	ARM7TDMI
Performance Characteristic	Position Accuracy	Without aid: 3.0m 2D-RMS <3m CEP(50%) without SA(horizontal) DGPS (WAAS, EGNOS, MSAS):2.5m
	Velocity Accuracy	Without aid: 0.1m/s DGPS (WAAS, EGNOS, MSAS): 0.05m/s
	Acceleration	Without aid: <4g DGPS (WAAS,EGNOS,MSAS): <4g
	Timing Accuracy	50 ns RMS
	Reacquisition Time	<1s
	Hot start	1s
	Warm start	33s
	Cold start	36s
	Sensitivity	Acquisition: -144dBm (Cold start) Tracking: -158dBm
	Update	1Hz
Dynamic	Altitude	Maximum 18,000m
	Velocity	Maximum 515m/s
	Acceleration	Maximum 4g
Power	Input Voltage	Vin: DC 5.0V ± 10%
	Power Consumption	42 mA
	Battery	Built-in rechargeable 1000mAH Lithium battery
Protocols	GPS Output Data	Baud rate 115200 bps, Data bit: 8, Stop bit: 1 (Default)
		NMEA 0183 v3.01(Default: GGA, GSA, GSV, RMC)
Environment	Operating Temperature	-10 ~ 60°C
	Storage Temperature	-20 ~ 60°C
	Charging	0 ~ 45°C
Bluetooth	Standard	Fully compliant with Bluetooth V1.2
	Output Power	0dBm (Typical), ClassII
	Range	Up to 15 meters
	Bluetooth Profile	Serial Port Profile(SPP)
	Frequency	2.4G ~ 2.4835GHz ISM Band
	Security	Yes
Physical Characteristics	Dimension	46.5 x72.2 x20 mm
	Weight	64.7g
