CF
(Compact flash) to 3.5"IDE Adapter for Desk PC
40
Pin Female V.E0
40PIN
FEMALE V.EO CF To IDE (IDE-CF) Adapter is an adapter for connecting a
compact flash memory card to a 3.5'' host interface, aiming
at
educational sectors, IT development, and the embedded technology
enthusiast to enable the use of a compact flash card as an IDE hard
drive.Designedto plug directly into the IDE port of any processor
board, the small form factor of this adapter can be easily mounted
inside any system.
Specification
& Features
- Support
single CF in this adapter
- Very helpful for embedded
system designers and engineers
- No driver required
- Master
/ Slave mode selection
- Male , 40-pin IDE connector
with 4-pin power connector on-board
- You
can boot from Dos/Windows/Linux with CF, same as IDE hard drives, but
much faster Master/Slave jumper ,with DMA MODE,support CFI/CFII cards
- Power
input: +5V, floppy disk Drive power connector
DATASHEET:
Interface:
|
40-pin IDE 3.5" |
| Supported media |
Type I/II CF and MicroDrive |
| Maximum
Read / Write Speed: | Depends
on the media | | OS Support: |
DOS, Windows 3.1, NT, 98SE, Me, 2000, XP,
Vista, Mac OS 8.6 or higher, Linux |
| Dimensions: |
(W x D x H) - 44 x 8 x 61 mm for 40-pin
IDE with CF card attached | | Power: |
+5V from PC power supply |
| Storage
Temperature: | -20
°C to + 60 °C | | Storage Humidity: |
5 - 90% |
