ASROCK N68C-VS3 UCC SOCKET AM3 MOTHERBOARD

Condition : New         Item at : Kuala Lumpur   , 46 views
ASROCK N68C-VS3 UCC SOCKET AM3 MOTHERBOARD
Click To Enlarge



Tell Friends

Share


Sale Price / Unit : RM 145.00 (Firm)
CheckOut & Pay Instantly
Add to Cart
Add to Watchlist (0 users)
Shipping Fee
We allow Combine Shipping
:
Peninsular :RM10
Sabah,Labuan:RM15
Sarawak:RM15
International:RM

Ship To : Within Malaysia
Shipping Method : POS Laju
Payment Method : Cheque, CreditCard, Maybank2U, TT / Wire, SafeTrade , Others :, PAYPAL

Time Left : 2 days (29 May 2012 6:39:00 PM)

Model / SKU / Code : 02.01.01.07
Available Qty : 29999
Remove banner from my ads, Click here


   Search Store
Keyword
Price -

< Get Store Plugin >
Product Description for ASROCK N68C-VS3 UCC SOCKET AM3 MOTHERBOARD


ASROCK N68C-VS3 UCC SOCKET AM3 MOTHERBOARD
Feature available to Store Members

ASROCK N68C-VS3 UCC AM3 MOTHERBOARD

Supports AM3 Socket
Phenom II X6, 6-Core CPU Ready
Supports ASRock UCC - Unlock CPU Core
Supports Dual Channel DDR3 1600
Integrated NVIDIA® GeForce 7025 graphics, DX9.0 VGA, Pixel Shader 3.0
Supports ASRock XFast USB, XFast LAN, Instant Boot, Instant Flash, OC Tuner, IES, OC DNA, APP Charger, SmartView



Product Specifications

General
CPU - Support up to 95W Socket AM3 processors: AMD Phenom™ II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors (For detail CPU support list, please click here)
- Supports Six-Core CPU
- Supports UCC feature (Unlock CPU Core)
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset - NVIDIA® GeForce 7025 / nForce 630a
Memory - Dual Channel DDR3 memory technology
- 2 x DDR3 DIMM slots
- Supports DDR3 1600/1333/1066/800 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB*

*Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.
BIOS - 4Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM Voltage Multi-adjustment
Audio, Video and Networking
Graphics - Integrated NVIDIA® GeForce 7025 graphics
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
- Supports D-Sub with max. resolution up to 1920x1440 @ 60Hz
Audio - 5.1 CH HD Audio (VIA® VT1705 Audio Codec)
LAN - Realtek PHY RTL8201EL
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
- Supports PXE
Expansion / Connectivity
Slots - 1 x PCI Express x16 slot
- 1 x PCI slot
Connector - 4 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Print Port header
- 1 x COM port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
Rear Panel I/O I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Other Features / Miscellaneous
Unique Feature - ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- ASRock AIWI
- ASRock APP Charger
- SmartView
- ASRock XFast USB
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
ASRock Software Suite (CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster X-Fi MB - Trial)
Accessories - Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (optional)
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
Form Factor - Micro ATX Form Factor: 8.5-in x 7.0-in, 21.6 cm x 17.8 cm
OS - Microsoft® Windows® 7 / 7 64-bit / Vista™ / Vista™ 64-bit / XP / XP 64-bit compliant
Certifications - FCC, CE, WHQL



For more details, please visit: Here

100% Genuine Products.

Come with Full New Standard Package

*3 Years Distributor Limited Warranty & Full Manufacturer Warranty*
