CF (Compact flash) to 3.5"IDE
Adapter with Mounting Bracket
40
Pin Male
40PIN MALE
CF To IDE (IDE-CF) Adapter is an adapter for connecting a compact flash
memory card to a 3.5'' host interface, aiming at educational
sectors, IT development, and the embedded technology enthusiast to
enable the use of a compact flash card as an IDE hard drive.Designedto
plug directly into the IDE port of any processor board, the small form
factor of this adapter can be easily mounted inside any system.
Specification & Features
- Support single CF in this adapter
- Very helpful for embedded system designers and
engineers
- No driver required
- Master / Slave mode selection
- Male , 40-pin IDE connector with 4-pin power
connector on-board
- You
can boot from Dos/Windows/Linux with CF, same as IDE hard drives, but
much faster Master/Slave jumper ,with DMA MODE,support CFI/CFII cards
- Power input: +5V, floppy disk Drive power connector
DATASHEET:
Interface:
|
40-pin IDE 3.5" |
| Supported
media |
Type I/II CF and MicroDrive |
| Maximum
Read / Write Speed: |
Depends on the media |
| OS Support: |
DOS, Windows 3.1, NT, 98SE,
Me, 2000, XP, Vista, Windiows 7, Mac OS 8.6 or higher, Linux |
| Dimensions: |
(W x D x H) - 44 x 12 x 61 mm
for 40-pin IDE with CF card attached |
| Power: |
+5V from PC power supply |
| Storage
Temperature: |
-20 °C to + 60 °C |
| Storage
Humidity: |
5 - 90% |
