Digital LCR Meter (Inductance / Capacitance / Resistance)
Current Price : RM 139.00 (Standard Auction) Condition : New
Main > Electronics & Appliances > Measuring Equipment
Description Biding Closed Q & A (0) Auction Info Current Bidder (0) Payment & Shipping

Product Description for Digital LCR Meter (Inductance / Capacitance / Resistance)



Description:
This instrument is a compact / battery operated / handheld / with safety protector / streamline 3.5 digital LCR multimeter designed for use by technicians, servicemen, students, and hobbyists who required an instrument that is accurate, reliable and always ready for use. The dual-slope-A/D converter uses C-MOS technology for auto-zeroing, polarity selection and over-range indication. Full overload protection is provided. It is powered by a standard 9V transistor radio type battery. Please read this manual that describes various useful message before using the multimeter.

Specification:
General Characteristics:
Display: 3 1/2 digit, character 16mm high, LCD screen, max. indication:1999
LED Back Lit
Auto-Zero &Auto-Polarity.
Over-range: indication of: "1" or"-1".
Low battery indication: support
Power supply: 9V Zinc-carbon battery.
Temperature for guaranteed accuracy: 23±5
Temperature range: Operating: 0 to 40   storage: -20 to 60
Humidity range: Operating: max 75%RH Storage: max 80%RH

Technical specifications
Resistance
Range 20Ω     Accuracy ±(1.2% of rdg + 30dgts)     Resolution 0.01Ω
Range 200Ω    Accuracy ±(1.0% of rdg + 20dgts)     Resolution 0.1Ω
Range 2KΩ     Accuracy ±(1.0% of rdg + 20dgts)     Resolution 1Ω
Range 20KΩ    Accuracy ±(1.0% of rdg + 20dgts)     Resolution 10Ω
Range 200KΩ   Accuracy ±(1.0% of rdg + 20dgts)     Resolution 100Ω
Range 2MΩ     Accuracy ±(2.0% of rdg + 30dgts)     Resolution 1KΩ
Range 20MΩ    Accuracy ±(2.0% of rdg + 25dgts)     Resolution 10KΩ
Range 200MΩ   Accuracy ±(5.0% of rdg + 25dgts)     Resolution 100KΩ
Range 2000MΩ  Accuracy ±(10.0% of rdg + 35dgts)    Resolution 1MΩ
Overload protection: 250V DC/250Vrms AC for all range.

Capacitance
Range  2000PF  Accuracy  ±(2.5% of rdg + 30dgts)    Resolution  1pF
Range  20nF    Accuracy  ±(2.5% of rdg + 25dgts)    Resolution  10pF
Range  200nF   Accuracy  ±(2.5% of rdg + 30dgts)    Resolution  100pF
Range  2uF     Accuracy  ±(2.5% of rdg + 30dgts)    Resolution  1nF
Range  20uF    Accuracy  ±(2.5% of rdg + 30dgts)    Resolution  10nF
Range  200uF   Accuracy  ±(7.0% of rdg + 50dgts)    Resolution  0.1uF

Inductance
Range  20mH    Frequency  100Hz   Accuracy  ±(2.5% of rdg + 25dgts)    Resolution  0.01mH
Range  200mH   Frequency  100Hz   Accuracy  ±(2.5% of rdg + 25dgts)    Resolution  0.1mH
Range  2H      Frequency  100Hz   Accuracy  ±(2.5% of rdg + 25dgts)    Resolution  1mH
Range  20H     Frequency  100Hz   Accuracy  ±(2.5% of rdg + 25dgts)    Resolution  10mH

Transistor hFE test
Range: hFE
Description: Display read approx. hFE value (NPN and PNP Type)
Test Consition: Bast Current approx 10uA Vce approx 3V

Dimension: 143*75*32mm
Weight: 210g
Powered by 1 x 9V (NEDA 6F22) battery (included)

Package include:
1* Digital multimeter
1* Operation manual
1* Set of test leads
1* Battery


poslaju: west malaysia RM10, sarawak RM8, sabah RM6. any question, feel free to contact me vester_syl(at)hotmail(dot)com or use the 'contact seller' button to contact me. no sms please.

 item will be fully tested before posting out. have a look at my other sales here:  http://members.lelong.com.my/Auc/List/List.asp?DataAction=Apply&UserID=vester_syl    buyers for more than 1 item can combine for shipping to safe cost.

payment can be made to my maybank or CIMB  account through any online transfer, atm transfer, atm cash deposit, bank counter cash deposit, cash deposit machine, etc. i'll send my bank details to your email within 24 hours after auction closed. please check your email inbox and junk/spam mail folder as well (sometimes the email will land in your junk/spam mail folder). after you've paid, please email me the exact amount paid, your shipping choice (pos daftar or poslaju), your mailing name, full address with post-code, and a valid telephone number as soon. item will be posted out within 2 working days after the fund is transfered. communicate through email only please. kindly settle the deal within 3 days after auction closed. thanks in advance.

please understand that we are web based trader and we don't meet up with buyers, so please don't insist on C.O.D. (self collect). thank you.
