Recordable DVD/CD Mobile Computer Drive. DVD +/-R, DVD +/-RW, CD-R/CD-RW Combination Drive, 8X Double Layer.

If your laptop/notebook has an internal CD drive you can replace it with this DVD +/-RW & CD-RW combo drive , so you can read CD & DVD disk, play DVD titles, write to CD-R, CD-RW, DVD +/-R, DVD +/- RW disk, back up your important files & data to DVD or CD disk.

With this slim combination drive, mobile PC users can now create DVD videos and CD audio files all with the same drive, allowing users to burn and edit both work-related and personal digital productions on the fly and on the go.

The lightweight combination drive brings DVD recording to the mobile world and gives users a stepping stone to move from CD to DVD technology for creating and storing family photos, files, videos and other memories they don?t want to lose. Based on the DVD +- R/RW format, combination drives support the most widely compatible DVD standard, giving consumers the highest level of compatibility with legacy DVD devices. This slim-drive supports writing DVD +-R/RW.

This powerful storage device is a functional technology that enables PC manufacturers to deliver unprecedented DVD and CD computing capabilities in their mobile devices. Until now, only desktop computers have had the luxury of DVD recordability for applications such as audio/video editing and personal digital compilations.

Features:

Supports for DVD+R/+RW, DVD-R/-RW, disc read & write

DVD+R Double Layer 2.4X

Defect management for reliable data writing

Buffer Under Run Free Technology

Specifications:

Data Transfer Rate Read CD: 3.6 MB/sec (24x)

Data Transfer Rate Read DVD: 10.8 MB/sec (8x)

Data Transfer Rate Write on CD Record: 3.6 MB/sec (24x)

Data Transfer Rate Write on CD Rewritable: 3.6 MB/sec (24x)

Data Transfer Rate Write on DVD-R: 10.8 MB/sec (8x)

Data Transfer Rate Write on DVD+R: 10.8 MB/sec (8x)

Data Transfer Rate Write on DVD-RW: 5.4 MB/sec (4x)

Data Transfer Rate Write on DVD+RW: 5.4 MB/sec (4x)

Double Layer: 2.4x write, 8x read

Data Transfer Rate Write on DVD-RAM: 5x write

Burst Transfer Rate PIO Mode 4: (16.6 MB/sec)

Burst Transfer Rate DMA Mode 2: (16.6 MB/sec)

Burst Transfer Rate Ultra DMA Mode 2: (33.3 MB/sec)

Recording Capacity CD-RW Disc: 700/650MB (Type 80/74)

Recording Capacity CD-R Disc: 800/700/650MB (Type 90/80/74)

Average Seek Time DVD-ROM: 110ms

Average Seek Time CD-ROM: 110ms

Drive Type: Internal

Interface: EIDE / ATAPI

Dimensions (WxHxDmm): 128 x 12.7 x 127

Buffer Memory: 2MB

Drive Mounting: horizontal/vertical

Supported Disc: DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-VIDEO, DVD-ROM, DVD-RAM, CD-R, CD-RW, CD-ROM, CD-ROM/XA, CD-Audio, Video-CD, Photo CD, CD-I(FMV), CD-Extra, CD-TEXT

Horizontal or Vertical Mount

External Dimensions (W x H x D): 128mm x 12.7mm x 129mm

Warranty: 1 Year limited warranty

BUS Interface

IDE Interface Connector, 50 Pin I/F ATAPI Standard

Burst Transfer Rate: PIO Mode 4 / Ultra DMA 33

Writing Methods:
DVD:Random Access Writing (DVD+/-RW), Sequential Writing 9DVD +/-R & DVD +/-RW)
CD: DAO (disc at once), SAO (session at once), TAO (track at once) with zero gap, variable or fixed packet, multisession

Compatibility: MPC Level 3, MultiRead, PC2001

Special Features: Vertical Operation Possible, Anti-Dust Seal, Anti "Buffer Under Run Error" system.

 If you don't see this drive directly listed under your notebook model, you can compare your current CD drive with this one. If your CD drive is seated inside a caddy, you need take it out from the caddy to do comparison:

Compare the CD Drive front bezel. This drive front bezel is straight rectangle shape. The dimension is: 0.5" (12.7mm) x 5.04" (128mm).


Tray Loading Drive Front Bezel

If your current CD drive front bezel is the same rectangle shape and dimension, then you can replace it with this DVD +/-RW drive.

Note: This CD Drive has a 50-pin ATAPI IDE Interface Connector as the picture shows:



Please contact Darren 0125190606 or Jerry 0123587654 for more info.
or email: sales@ezytronic.com
CREDIT CARD ACCEPTED (2% CHARGES)
COC at USJ 1, SUBANG JAYA
