DDr2 Sata MotherBoArd+pROCESSOR+hEATSINK not 478/775/AM2 mainboard

Click To Enlarge

JETWAY MOTHERBOARD - VIA Platform Hybrid Series

Jetway Hybrid Mini-ITX Motherboard Processor VIA C7 and Eden (V4) processors Chipset VIA CN700 + VT8237RP Chipset Memory 1 x DDR2 400/533 DIMM slot (up to 1 GB) Graphics VIA UniChrome™ Pro Integrated Graphics Core Audio VIA VT1617A 6 Channel AC 97 Audio LAN VIA VT6103 10/100 PCI LAN PHY Back Panel Connectors 1 PS/2 Mouse 1 PS/2 Keyboard 1 Serial (RS232) 1 VGA 2 USB 2.0 1 RJ45 LAN (10/100) 1 S-Video 1 RCA/Composite 3 3.5mm Audio Onboard I/O Connectors 1 PCI Slot 1 Floppy Connector 1 Parallel header 1 Serial header (RS232) 2 IDE Connector (UDMA 33/66/100) 2 SATA 1.5Gb/s Connectors with RAID 0, 1, JBOD 3 USB Pin Headers for up to 6 additional USB 2.0 Ports 1 9-pin 1394 header 1 4-pin CD Audio-in header 1 9-pin Audio Connector 1 Front Panel Connector 3 Fan Headers 1 24-pin ATX Power Connector Market Segments Supported Digital Security & Surveillance Digital Signage Gaming Industrial Automation/Control Medical Retail (POS/Kiosk/ATM) In-Vehicle Infotainment Networking/Storage Server/Mail Server/Print Server Thin Client Nettop



Extremely versatile, Jetway board with brand new LOW POWER consumption and ultra-low profile form factor (less than 5cm high). All on board COME WITH I/O back plate

CONDITION :  EXCELLENT !

  MOTERBORD WITH ALL SOLID CAPACITORS

PICTURE SHOWN AS REAL ITEM YOU WILL GET

Mainboard complete with Processor + Heatsink + Fan, 2D 3D Graphic VGA, support 8x USB, VIA Lan,

on board Audio & connector, 2x Sata, single DDr2 slot, S-Video,TV-out port and more details as follow:

 Built-inBuilt-In VIA C7 processor 1500mhz

( Processor, Fan & Heatsink Included as picture shown )

On board VIA UniChrome Pro Graphic

( screen resolution: 1200 x 1600, 128 bit 2D 3D graphic )

On board VIA Lan

( Support for VIA Velocity Gigabit Ethernet companion controller & Integrated 10/100 Fast Ethernet )

On board Audio, S-Video, TV-Out

( Support for VIA Vinyl Gold 8-channel HD Audio Controller & integrated VIA Vinyl 6-channel HD Audio )

Support 8 USB 2.0/usb  1.1 port

( 2x on board USB and 3x USB 2.0/1.1 connector (supports 2 ports each connector)

Support 1GB DDR2 Memory Ram, 533/400mhz

( single slot for DDr2)

Two SATA

( support for two 150MB/s Serial ATA devices and its unique SATAlite™ interface expands for additional SATA devices )

 Key Features

» Supports up to 1.0GB DDR2 533/400MHz or DDR400/333/266MHz SDRAM
» 533 MB/sec 8-bit V-Link Host Controller supporting V-Map Modular Architecture
» Chromotion CE Video Display engine
» MPEG-2 Decoder
» Video De-blocking
» Adaptive De-Interlace
» DuoView+™
» Integrated VIA UniChrome Pro Graphics
» Optimized Unified memory Architecture (UMA)
» 200MHz Graphics Engine Clock with separated 128-bit data paths
» 128-bit 2D and 3D Graphics engine
» 12-bit DVI transmitter
» 24-bit Flat Panel Display Interface and Dual 12-bit Flat Panel Display Interface
» 12-bit interface to external TV encoder for SDTV and HDTV display
» Support for VIA Vinyl Gold 8-channel HD Audio Controller & integrated VIA Vinyl 6-channel HD Audio
» Serial ATA support for up to 4 devices
» Integrated V-RAID 0, RAID 1, and RAID 0+1*, and JBOD (SATA) support
» Parallel ATA133/100/66 support for up to 4 devices
» Support for up to 8 USB 2.0/USB 1.1 ports
» Support for VIA Velocity Gigabit Ethernet companion controller & Integrated 10/100 Fast Ethernet
» Advanced System Power Mana  gement Support

  DEALING METHOD :

On-Line transfer or Cash Bank-In.
No Cash On Delivery and self-collect as we are online seller and not shop seller

contact method : mikewilfrey@gmail.com (preferable)

After Payment please inform seller within 3 days once the e-mail received.
Item will not be ship out, if there is no advice on your Full Payment and Shipping Details. Therefore, to avoid any delay in delivery, please Email us details right after your payment has been done.


(Online bank transfer/ Cash Deposit / ATM/ Giro/ Cheque deposit)
Key in my email address: mikewilfrey@gmail.com in the 3rd party email address field so we will received notification from Maybank2u.


DELIVERY : POSLAJU

STOCK :  MANY units available and you are welcome to order by Lelong PM system, thanks!

ORDER : Order,  provide your mailing address, name and contact for further proceed of payment.

Your inquiry by Lelong PM will CONFIRM reply within 12 hour

Thanks For Viewing

" wilfrey " as LELONG VERIFIED MEMBER with IC SUBMITTED, 100% ON-LINE GENUINE SELLER

Last Updated @ 3/20/2012 9:46:13 PM
