The PROLiNK® PIC1003WP Wireless IP camera with pan/tilt is designed with the "user-friendly" idea deep in mind. The user can install the PIC1003WP easily on his/her home network and then access the IP Camera anywhere in the world through the accompanied video management software-mLiveView without setting some complicated DNS name or changing the router's settings. It's just a plug & play action.
With 3GPP/ISMA support, users can see the video of the IP camera on iPhone and Android (V2.2 and above) 3G phone anywhere, anytime. The big difference is that there is software apps for downloading to the mobile phone so that the fixed IP address is not needed for the IP camera. The video settings including frame rate, resolution and bandwidth could be different for monitoring and mobile viewing.
With pan/tilt support, users can monitor the video in a much larger viewing angle range.
For indoor surveillance and remote monitoring, the PIC1003WP provides the best image quality in its class, and excellent performance. The PIC1003WP also provides the best bandwidth efficiency, it offers 640x480 resolution, 30 fps frame rate, real MPEG4 image compression ability. The built-in microphone enables remote users to not only view, but also listen for additional monitoring options.
The NAS storage function can easily turn any NAS device to a NVR device. The schedule function provides full scheduling of email/ftp sending, motion detection and NAS recording event. With the built-in Web server, the PIC1003WP can also be managed from a standard web browser on a Windows computer. With the ActiveX support, users can also see the video display on the Windows IE browser.
The PIC1003WP IP Camera provides motion detection function. Users can easily setup this function and receive the notification with the snapshot images through email and/or ftp when some motion events are detected.
The PIC1003WP provides both wireless IEEE 802.11 b/g and wired Ethernet network interfaces for flexible installation. It supports the WEP and WPA (Wi-Fi Protected Access) security modes to provide the best security for wireless networks.
Truly Plug and Play
- Auto‐IP is Plug & Play Solution as easy as USB Webcam
- No router settings, Auto network configuration
Just Key-in ID/Password and enjoy IP video from anywhere in the world
Support all Apple iOS and Android devices.
DC 5V, 2A
RISC CPU, hardware video processing and compression.
Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45
IEEE 802.11g 6 - 54 Mbps
IEEE 802.11b 1 - 11 Mbps
Transmit power: 14.5dBm typically @ 802.11g
17.5dBm typically @ 802.11b
Receiver sensitivity: 54Mbps: Typical -73dBm @ 10% PER
11Mbps: Typical -86dBm @ 10% PER
Antenna gain: 1.8 dBi
Pan range 130° ( -65° ~ 65° )
Tilt range 90° ( 0° ~ 90° )
Auto pan mode
Auto patrol mode
RGB VGA 1/4 inch CMOS
Automatic exposure control, automatic white balance, automatic gain control, automatic brightness control.
3.2 mm, F2.0, viewing angle: 60.3°, fixed iris.
focus range: 30 cm to infinity
D/I D/O interface
1 D/I for alarm detection
1 D/O for alarm triggering
Micro-SD card interface
Micro-SD card interface for local video storage
The supported Micro SD-Card capacity is up to 16G bytes.
One reset button, to factory default settings
One LED for internet connection status indication
One LED for Ethernet connection indication
Enable/disable web configurable
MPEG-4 Part 2 (ISO/IEC 14496-2) with motion detection, profiles:
Simple Profile, level 0-3
Up to 30 fps in all resolutions
Separate frame rate/resolution/bandwidth settings for PC and mobile.
Resolution: VGA(640x480), QVGA(320x240), QQVGA(160x120)
Bandwidth : 64k, 128k, 256k, 512k, 768k, 1M, 1.2M, 1.5M bps
Frame rate : 1~5, 10, 15, 20, 25, 30 fps
Built-in microphone for audio monitoring
MP2 audio, AMR-NB for 3GPP/ISMA(RTSP streaming)
Web management username/password protection
Video display ID/password protection
WiFi WEP and WPA security mode
Installation, management and maintenance
Installation tool on CD and Web-based configuration
Automatic configuration backup and restore
Video management software-CamView for video access and multi-camera management
Firmware upgrades via FTP
Minimum Web browsing and management software apps requirements
Built-in web server for standard web browser access
Pentium 4(or equivalent AMD) CPU 1.0 GHz or higher, 1 GB RAM
IPv4, HTTP, TCP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, SNTP, FTP, DHCP, ARP, DNS, PPPoE, etc
Power adaptor, RJ45 ethernet cable, quick installation guide, CD with installation tool/software apps and Users Manual, ID/Password card.
Video management software apps Users
Surveillance application for viewing and archiving up to 16 cameras
Up to 36 simultaneous unicast users
(depends on video settings)
Alarm and event management
Events triggered by video motion detection
Notification/upload of JPEG images over FTP and/or email
Dimensions (HxWxD) and weight
120 x 91 x 84 mm,
350 g, camera body only.
EMC - CE, FCC Part 15 Subpart B Class B
Wireless RF - CE, FCC Part 15 Subpart C
Power supply: CE, FCC, UL, EN 60950
Humidity 20 - 80% RH (non-condensing)
** Specifications in this datasheet are subject to change without prior notice.
