Element V NVIDIA Edition Basic VL200N1W2Z |
|
|
|
|
Features
Velocity - With biggest graphics expansion space: NVIDIAR SLIR - ready.
Visual - The all black coating, inside and outside, adds overall quality and neat looks.
Voodoo - Colorshift Fan with 6 color changing pattern for optimal gaming experience.
Vivid - Three color shifting fans creates most eye catching appearance.
Vary - Adjustable fan speed control for performance mode or silent mode.
Ventilation - Excellent thermal performance with optimized air flow.
Vast - Support up to 11 x 5.25” drive bay or 5 x 5.25” and 6 x 3.5” with 2 iCage
Cooling System
 |
CPU Air Cooling System
? Side (intake) 230mm x 1 :
230 x 230 x 20 mm Colorshift fan
?Top (exhaust)200mm x 2:
200 x 200 x 20 mm Colorshift fan
200 x 200 x 20 mm x 1 (optional)
? Rear (exhaust) 120mm x 1:
120 x 120 x 25 mm TurboFan
HDD Air Cooling System
? Front (intake) 120mm x 2:
120 x 120 x 25 mm Colorshift fan
120 x 120 x 25 mm Turbo fan
VGA Air Cooling System
? Side (intake)230mm:
230 x 230 x 20 mm Colorshift fan
? Rear (exhaust)50mm x 2:
50 x 50 mm fan x 2 (optional) |
|
P/N |
VL200N1W2Z |
|
Case Type |
Full Tower |
|
Dimension (H x W x D) |
532 x 220 x 537 mm (20.9 x 8.7 x 21.1 inch) |
|
Net Weight |
15.0 kg / 33.1 lb |
|
Side Panel |
Transparent Window |
|
Color |
Exterior & Interior : Black |
|
Material |
1.0 mm SECC |
|
Cooling System |
Front (intake) :
120 x 120 x 25 mm Colorshift Front (intake) :
120 x 120 x 25 mm Colorshift fan x 1 (1000~1400rpm,17dBA)
120 x 120 x 25 mm Turbo fan x 1 (1400rpm,17dBA)
Rear (exhaust) :
120 x 120 x 25 mm Turbo fan x 1 (1400rpm,17dBA)
Top (exhaust) :
200 x 200 x 20 mm Colorshift fan x 1 (600~800rpm, 12~14dBA);
200 x 200 x 20 mm (optional)
VGA (exhaust) :
50 x 50 mm fan x 2 (optional)
Side (intake) :
Plug & Play 230 x 230 x 20 mm Colorshift fan (600~800rpm, 13~15dBA) |
|
Drive Bays |
5 x 5.25’’, 1 x 3.5’’ (Converted from one 5.25” drive bay)
6 x 3.5’’, 1 x 2.5’’ |
|
Expansion Slots |
7 |
|
Motherboards |
9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) , 12” x 13” (Extend ATX) |
|
I/O Ports |
USB 2.0 x 4, eSATA x 1, MIC & Speaker (support AC’97 & HD Audio) |
|
PSU |
Standard ATX PS2 (optional) |
|
LCS Upgradable |
Supports 1/2”、3/8”、1/4” water tube |
|
Adjustable PSU Bridge |
Yes |
|
Other |
CPU cooler height limitation: 155mm
VGA length limitation: 335mm |
|
Element V NVIDIA Edition Basic VL200N1W2Z |
|
|
|
Keyboard & mouse security lock
|
  |
|
|
Reviewed by tech REACTION |
|
Thermaltake Element V – Black Edition |
|
|
|
The Thermaltake Element V is a massive, full-tower case able to handle just about anything you throw at it. As you could see in the installation, it held our GTX 590 with no problem at all, with plenty of clearance between it and the 5.25? bay area. The latches on the side panel provide a little extra security for your hardware, because you can lock it to help prevent unwanted access. The airflow provided by the Element V is good enough to keep all your precious hardware nice and cool .. |
|
|
|
June 15, 2011 |
|
|
|
 |
|
|
Reviewed by PC Mag |
|
AMD Radeon HD 6990 |
|
|
|
The 6990 is also physically big. Like the 5970, it measures 12.5 inches in length, making it the longest card you can buy. Trying to house it in anything less than a full-tower case is taking a real chance .. |
|
|
|
March 08, 2011 |
|
|
|
 |
|
|
Reviewed by CDRinfo |
|
Thermaltake Element V Case review |
|
|
|
Thermaltake Element V is has solid construction, great quality and offers many extra features that will make your everyday activity with the system easy and fun .. |
|
|
|
October 01, 2010 |
|
|
|
 |
|
|
Reviewed by Overclockers Online |
|
Thermaltake Element V |
|
|
|
I’d happily recommend this case to anyone looking for a good looking full-size case at a modest price point .. |
|
|
|
August 02, 2010 |
|
|
|
 |
|
|
Reviewed by BCCHardware |
|
Thermaltake Element V Full Tower Case |
|
|
|
The Element V Full Tower Case from Thermaltake has very easily earned our BCCHardware "Editor's Choice - Gold" award thanks to the abundance of features this case offers for a very affordable MSRP. If you need room for tons of hard drives and optical drives and want a case that is very solid, the Element V just might be a great choice for you. .. |
|
|
|
June 07, 2010 |
|
|
|
|
|
 |
|
|
Reviewed by Tom's Hardware |
|
Thermaltake Wins! |
|
|
|
The Element V thus gets our recommendation, with the reservation that buyers may need to exchange theirs if they encounter similar panel-fitment issues .. |
|
|
|
March 23, 2010 |
|
|
|
 |
|
|
Reviewed by UMLan |
|
Thermaltake Element V |
|
|
|
Element V is a great case and has a great potential in the current gamers market. It gives me a great pleasure to award Element V a highest rank of 10/10! .. |
|
|
|
March 18, 2010 |
|
|
|
|
|
 |
|
|
Reviewed by TweakTown |
|
|
|
|
|
The Element V is an impressive chassis in both size and features .. |
|
|
|
March 03, 2010 |
|
|
  |
