Asus ROG Capture GT6 AX10000 Wifi 6 Gaming Mesh System - Black

ROG Rapture GT6

Model Name

GT6

Design

Black

Moonlight White

Network Standard

WiFi 6 (802.11ax)

IPv4

IPv6

Backwards compatible with 802.11a/b/g/n/ac Wi-Fi

Product Segment

AX10000 ultimate AX performance

AX technology

Yes

Antenna

Internal antenna x 9

Transmit/Receive

2.4GHz 2x2

5GHz-1 4x4

5GHz-2 4x4

Processor

1.7GHz tri-core processor

Memory

256MB Flash 512MB DDR4 RAM

Boosts speed

OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth * The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions.

Operating Frequency

2.4G Hz, 5 GHz-1, 5 GHz-2

Ports

1 x 2.5 Gigabit WAN Port 3 x Gigabit LAN Ports 1 x USB 3.2 Gen 1x1 Port

Button

WPS Button, Reset Button, Power Switch

LED Indicator

Power x 1

Power Supply

AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 2.37 A current / 19.5 V with max. 2.31 A current

Package content

ROG Rapture GT6 RJ-45 Cable Power Adapter Quick Start Guide Warranty Card

Product Weight (g)

880 g

AiMesh

AiMesh

Primary AiMesh router

AiMesh node

Router APP

ASUS Router APP

Game

Game Boost/acceleration

Game Radar

WTFast

ROG_First

OpenNAT (Game Profile)

Gaming port

Alexa

Support Alexa skill

AiProtection

AiProtection Pro

Router Security Assessment

Malicious site blocking

Two-Way IPS

Infected Device Prevention and Blocking

Parental Control

Parental Control

Parental Control Customized Internet schedule

Traffic Control

Adaptive QoS

Bandwidth Monitor

Bandwidth limiter

Traditional QoS

Traffic Monitor

Real-time traffic monitor

Wired Traffic Monitor

Wireless Traffic Monitor

Traffic Analyzer

Traffic analysis period : Daily, Weekly, Monthly

Website history

Wireless

IPv6

MU-MIMO

WiFi Encryption : WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, Open System

UTF-8 SSID

Guest Network

Guest Network Connection time limit

WPS

Wi-Fi MAC address filter

Maximum MAC filters : 64

Wireless scheduler

Wi-Fi Radar

Airtime fairness

RADIUS Client

Universal beamforming

USB application

File System : HFS+, NTFS, vFAT, ext2, ext3, ext4

Safely Remove disk

AiCloud

Download master

AiDisk

Media Server

Time Machine

Samba Server

FTP Server

Shared Folder privileges

Administration

Operating mode : Wireless router mode Access point mode

Free OS upgrade

Firewall

Maximum Firewall keyword filter : Max 64 rules

Maximum Firewall network service filter : Max 32 rules

Maximum Firewall URL filter : Max 64 rules

Wake on LAN (WOL)

SSH

Configuration backup and restore

Diagnosis tools

Feedback system

System log

New Device Connect Notification

Login Captcha

Connection Diagnosis

Security Scan

Auto Firmware Update
