Model Name |
GT-AX6000 |
Network Standard |
IEEE 802.11a |
|
IEEE 802.11b |
|
IEEE 802.11g |
|
IEEE 802.11n |
|
IEEE 802.11ac |
|
IEEE 802.11ax |
|
IPv4 |
|
IPv6 |
Product Segment |
AX6000 ultimate AX performance |
AX technology |
Yes |
Data Rate |
2.4GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps |
|
5GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps |
Antenna |
External antenna x 4 |
Transmit/Receive |
2.4 GHz 4 x 4 |
|
5 GHz 4 x 4 |
Processor |
2.0 GHz quad-core processor |
Memory |
256 MB Flash, 1 GB RAM |
Boosts speed |
OFDMA (Orthogonal Frequency Division Multiple Access), |
|
Beamforming: standard-based and universal, |
|
1024-QAM high data rate, |
|
20/40/80/160 MHz bandwidth, |
Operating Frequency |
2.4G Hz / 5 GHz |
Ports |
RJ45 for 2.5 Gigabits BaseT for WAN/LAN x 1, |
|
RJ45 for 2.5 Gigabits BaseT for LAN x 1, |
|
RJ45 for Gigabits BaseT for LAN x 4, |
|
USB 3.2 Gen 1 x 1, |
|
USB 2.0 x 1 |
Button |
WPS Button, |
|
Reset Button, |
|
Power Button, |
|
LED Control Button |
LED Indicator |
Power x 1 |
|
2.4GHz x 1 |
|
5GHz x 1 |
|
2.5G WAN x 1 |
|
2.5G LAN x 1 |
|
LAN x 1 |
|
WPS x 1 |
Power Supply |
AC Input : 110V~240V(50~60Hz) |
|
DC Output : 19 V with max. 2.37 A current or 19.5 V with max. 2.31 A current |
Package content |
GT-AX6000 WiFi 6 Dual-Band Gaming Router |
|
RJ-45 cable |
|
Power Adapter |
|
Quick Start Guide |
|
Warranty Card |
Product Weight (g) |
1121.4 g |
AiMesh |
AiMesh : Yes |
|
Primary AiMesh router : Yes |
|
AiMesh node : Yes |
Router APP |
ASUS Router APP : Yes |
Game |
Game Boost/acceleration : Yes |
|
ROG_First : Yes |
|
OpenNAT (Game Profile) : Yes |
|
Gaming port : Yes |
AiProtection |
AiProtection : AiProtection Pro |
|
Router Security Assessment : Yes |
|
Malicious site blocking : Yes |
|
Two-Way IPS : Yes |
|
Infected Device Prevention and Blocking : Yes |
Parental Control |
Parental Control : Yes |
|
Parental Control Customized Internet schedule : Yes |
Traffic Control |
Adaptive QoS : Yes |
|
Bandwidth Monitor : Yes |
|
Bandwidth limiter : Yes |
|
Maximum Bandwidth limiter rule : 32 |
|
Traditional QoS : Yes |
|
Maximum Traditional QoS rule : 32 |
|
Traffic Monitor : Yes |
|
Real-time traffic monitor : Yes |
|
Wired Traffic Monitor : Yes |
|
Wireless Traffic Monitor : Yes |
|
Traffic Analyzer : Yes |
|
Traffic analysis period : Daily, Weekly, Monthly |
|
Website history : Yes |
Wireless |
IPv6 : Yes |
|
MU-MIMO : Yes |
|
Wi-Fi Encryption : Open system, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise |
|
UTF-8 SSID : Yes |
|
Guest Network : Yes |
|
Maximum Guest Network rule : 2.4GHz x3, 5GHz x3 |
|
Guest Network Encryption : Open system, WPA/WPA2/WPA3-Personal |
|
WPS : Yes |
|
Wi-Fi MAC address filter : Yes |
|
Maximum MAC filters : 64 |
|
Wireless scheduler : Yes |
|
Airtime fairness : Yes |
|
RADIUS Server : Yes |
|
Universal beamforming : Yes |
WAN |
Explicit beamforming : Yes |
|
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP |
|
Dual WAN : Yes |
|
WAN Aggregation : Yes |
|
3G/4G LTE dongle : Yes |
|
Android tethering : Yes |
|
Port forwarding : Yes |
|
Maximum port forwarding rule : 64 |
|
Port triggering : Yes |
|
Maximum port triggering rule : 32 |
|
DMZ : Yes |
|
DDNS : Yes |
|
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay |
LAN |
DHCP Server : Yes |
|
IGMP snooping : Yes |
|
IPTV : Yes |
|
LAN Link Aggregation : Yes |
|
Manually assign IP address : Yes |
|
Maximum manually assign IP address rule : 64 |
VPN |
VPN Client L2PT : Yes |
|
VPN Client OVPN : Yes |
|
VPN Client PPTP : Yes |
|
VPN Server IPSec : Yes |
|
VPN Server OVPN : Yes |
|
VPN Server PPTP : Yes |
|
VPN Fusion : Yes |
USB application |
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 |
|
HDD hibernation : Yes |
|
Safely Remove disk : Yes |
|
AiCloud : Yes |
|
Download master : Yes |
|
AiDisk : Yes |
|
Media Server : Yes |
|
Time Machine : Yes |
|
Samba Server : Yes |
|
FTP Server : Yes |
|
Shared Folder privileges : Yes |
Administration |
Operating mode : Accesspoint, AiMeshnode, Mediabridge, Repeater, Router |
|
Operating system : ASUSWRT |
|
Free OS upgrade : Yes |
|
Firewall : Yes |
|
Maximum Firewall keyword filter : 64 |
|
Maximum Firewall network service filter : 32 |
|
Maximum Firewall URL filter : 64 |
|
Wake on LAN (WOL) : Yes |
|
SSH : Yes |
|
Configuration backup and restore : Yes |
|
Diagnosis tools : Yes |
|
Feedback system : Yes |
|
System log : Yes |
