IMAGE SENSOR: 1/4"Sharp CCD
CCD TOTAL PIXELS: NTSC: 537 (H)X505 (V)
PAL: 537 (H)X597 (V)
SCANNING SYSTEM: NTSC: 525 lines, 60 fields/sec
PAL: 625 lines, 50 fields/sec
SYNC SYSTEM: Internal
MINIMUM ILLUMINATION: 0.5 Lux F1.2 0 Lux(IR ON)
RESOLUTION: 420 TV Line
HITE BALANCE: ATW / AWC Switch able
GAIN CONTROL: AGC ON / OFF switchable
S/N RATIO: 48dB (AGC OFF)
ELECTRONIC SHUTTER: NTSC: 1/60~1/120,000 sec.
PAL: 1/50~1/120,000 sec.
B.L.C. FUNCTION: ON/OFF switchable
VIDEO OUTPUT: Composite 1.0V p-p at 75 ohm
GAMMA CORRECTION: 0.45
LENS: Board Lens mount
IR LED: 30 pcs φ8 IR LEDS
VISIBLE DISTANCE AT: 70m (Lens 16mm)
OPERATION TEMPERATURE:-10℃ TO 50℃
OPERATIONAL HUMIDITY: within 85%RH
POWER SUPPLY:DC12V±1V / 700mA
DIMENSIONS (L x W x H):132X86X78
Weight-Net:770g
SN-LB3140GP IR CCD camera
IMAGE SENSOR: 1/3" Sharp CCD
CCD TOTAL PIXELS: NTSC: 811 (H)X508 (V)
PAL: 795 (H)X596 (V)
SCANNING SYSTEM: NTSC: 525 lines, 60 fields/sec
PAL: 625 lines, 50 fields/sec
SYNC SYSTEM: Internal
MINIMUM ILLUMINATION: 0.8 Lux F1.2 0 Lux(IR ON)
RESOLUTION: 420 TV Line
WHITE BALANCE: ATW / AWC Switchable
GAIN CONTROL: AGC ON / OFF switchable
S/N RATIO: 48dB (AGC OFF)
ELECTRONIC SHUTTER: NTSC: 1/60~1/120,000 sec.
PAL: 1/50~1/120,000 sec.
B.L.C. FUNCTION: ON/OFF switchable
VIDEO OUTPUT: Composite 1.0V p-p at 75 ohm
GAMMA CORRECTION: 0.45
LENS: Board Lens mount
IR LED: 30 pcs φ8 IR LEDS
VISIBLE DISTANCE AT: 70m (Lens 16mm)
OPERATION TEMPERATURE:-10℃ TO 50℃
OPERATIONAL HUMIDITY :within 85%RH
POWER SUPPLY:DC12V±1V / 700mA
DIMENSIONS(L x W x H):132X86X78
Weight-Net:770g
SN-LB3142GP IR CCD camera
IMAGE SENSOR: 1/3"Sony Super HAD CCD
DSP: Sony
CCD TOTAL PIXELS: NTSC: 811 (H)X508 (V)
PAL: 795 (H)X596 (V)
SCANNING SYSTEM: NTSC: 525 lines, 60 fields/sec
PAL: 625 lines, 50 fields/sec
SYNC SYSTEM: Internal
MINIMUM ILLUMINATION: 0.8 Lux F1.2 0 Lux(IR ON)
RESOLUTION: 420 TV Line
WHITE BALANCE: ATW / AWC Switchable
GAIN CONTROL: AGC ON / OFF switchable
S/N RATIO: 48dB (AGC OFF)
ELECTRONIC SHUTTER: NTSC: 1/60~1/120,000 sec.
PAL: 1/50~1/120,000 sec.
B.L.C. FUNCTION: ON/OFF switchable
VIDEO OUTPUT: Composite 1.0V p-p at 75 ohm
GAMMA CORRECTION: 0.45
LENS: Board Lens mount
IR LED: 30 pcs φ8 IR LEDS
VISIBLE DISTANCE AT: 70m (Lens 16mm)
OPERATION TEMPERATURE:-10℃ TO 50℃
OPERATIONAL HUMIDITY :within 85%RH
POWER SUPPLY:DC12V±1V / 700mA
DIMENSIONS(L x W x H):132X86X78
Weight-Net:770g
SN-LB3148GP IR CCD camera
IMAGE SENSOR: 1/3"Sony Super HAD CCD
DSP: Sony
CCD TOTAL PIXELS: NTSC: 811 (H)X508 (V)
PAL: 795 (H)X596 (V)
SCANNING SYSTEM: NTSC: 525 lines, 60 fields/sec
PAL: 625 lines, 50 fields/sec
SYNC SYSTEM: Internal
MINIMUM ILLUMINATION: 0.8 Lux F1.2 0 Lux(IR ON)
RESOLUTION: 480 TV Line
WHITE BALANCE: ATW / AWC Switchable
GAIN CONTROL: AGC ON / OFF switchable
S/N RATIO: 48dB (AGC OFF)
ELECTRONIC SHUTTER: NTSC: 1/60~1/120,000 sec.
PAL: 1/50~1/120,000 sec.
B.L.C. FUNCTION: ON/OFF switchable
VIDEO OUTPUT: Composite 1.0V p-p at 75 ohm
GAMMA CORRECTION: 0.45
LENS: Board Lens mount
IR LED: 30 pcs φ8 IR LEDS
VISIBLE DISTANCE AT: 70m (Lens 16mm)
OPERATION TEMPERATURE:-10℃ TO 50℃
OPERATIONAL HUMIDITY :within 85%RH
POWER SUPPLY:DC12V±1V / 700mA
DIMENSIONS(L x W x H):132X86X78
Weight-Net:770g
SN-LB3152GP IR CCD camera
IMAGE SENSOR: 1/3"Sony Super HAD CCD
DSP: Sony
CCD TOTAL PIXELS: NTSC: 811 (H)X508 (V)
PAL: 795 (H)X596 (V)
SCANNING SYSTEM: NTSC: 525 lines, 60 fields/sec
PAL: 625 lines, 50 fields/sec
SYNC SYSTEM: Internal
MINIMUM ILLUMINATION: 0.8 Lux F1.2 0 Lux(IR ON)
RESOLUTION: 520 TV Line
WHITE BALANCE: ATW / AWC Switchable
GAIN CONTROL: AGC ON / OFF switchable
S/N RATIO: 48dB (AGC OFF)
ELECTRONIC SHUTTER: NTSC: 1/60~1/120,000 sec.
PAL: 1/50~1/120,000 sec.
B.L.C. FUNCTION: ON/OFF switchable
VIDEO OUTPUT: Composite 1.0V p-p at 75 ohm
GAMMA CORRECTION: 0.45
LENS: Board Lens mount
IR LED: 30 pcs φ8 IR LEDS
VISIBLE DISTANCE AT: 70m (Lens 16mm)
OPERATION TEMPERATURE:-10℃ TO 50℃
OPERATIONAL HUMIDITY :within 85%RH
POWER SUPPLY:DC12V±1V / 700mA
DIMENSIONS(L x W x H):132X86X78
Weight-Net:770g
Application
Finance & Stock MarketApartmentEntertainmentCasinoAirportMilitaryJewel Shops
Hospital Car Park Supper MarketRestaurant Mass Transit Super MarketRestaurant
Mass Transit
