Product ID : 221855938
Model / SKU : H803
Conditions : New
|
LIMITED TIME OFFER: FREE P2P ACCOUNT UPON PURCHASE NOW
|
Product parameters |
MODEL: APM-HP803-MPC-WS Wireless Network Camera, Wireless IP Camera, Wireless P2P IP Camera
New Feature:
> Support Plug and Play function
> Support IR-Cut
> Support Gmail/Hotmail function
> 9 preset positions monitoring
> Free DDNS for Remote viewing
> Freely control alarm sound ON/OFF
> Freely control alarm record ON/OFF
> 1.0MegaPixel
Basic Feature:
> H.264 video compression format
> SD2.0 standard, maximum storage upto 32GB
> Built-in Microphone and Speaker
> Support two-way audio function
> Freely control upload image to FTP
> Freely control Pan/Tilt angle by software
> Freely control Pan/Tilt speed by software
> Freely control network indicator LED on/off
> Support up to 9 users online simultaneously
> Motion detection alert with snapshots via email
> Allow remote view & record from anywhere anytime
> Multi-level user management with password protection
> Wi-Fi compliant with wireless standards IEEE 802.11b/g/n
> Support both WEP & WPA WPA2 encryption for wireless
> Support Mobile phone login from User Interface via browser directly
> Support IE, Safari, Firefox, Google chrome browser or any other standard browsers
|
Specification:
|
Model: APM-HP803-MPC-WS
|
|
Image? Sensor
|
Image Sensor
|
1/4" Color CMOS Sensor
|
|
Display Resolution
|
Primary Stream: 1280*720 (30fps), 640*368 (30fps)C320*208 (30fps)
|
|
Lens
|
f: 6 mm, F:2.0 (IR Lens)(3.6mm lens optional)
|
|
Mini. Illumination
|
0.5Lux
|
|
Lens
|
Lens Type
|
Glass Lens
|
|
Viewing Angle
|
60°(3.6mm lens is 90°)
|
|
Audio
|
Input
|
Built-in Microphone/1 channel audio input
|
|
Output
|
Built-in Speaker
|
|
Audio Compression
|
ADPCM
|
|
Video
|
Image Compression
|
H.264, MJPEG
|
|
Image Frame Rate
|
15fps(VGA),30fps(QVGA)
|
|
Resolution
|
1280*720 (30fps), 640*368 (30fps)C320*208 (30fps)
|
|
Flip Mirror Images
|
Vertical / Horizontal
|
|
Light Frequency
|
50Hz, 60Hz, Outdoor
|
|
Video Parameters
|
Brightness, Saturation , Contrast ,Hue
|
|
Communication
|
Ethernet Interface
|
Build in 10/100Mbps,Auto MDI/MDIX,RJ-45
|
|
Supported Protocol
|
TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP ARP/RARP NFS RTSP RTP RTCP.
|
|
Wireless Standard
|
IEEE 802.11b/g/n
|
|
Data Rate
|
802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.), 802.11n: 150Mbps (Max.)
|
|
Wireless Security
|
WEP & WPA WPA2 Encryption
|
|
Physical
|
Pan/Tilt Angle
|
Horizontal:320° & Vertical: 120°
|
|
Infrared Light
|
16 IR LEDs,Night visibility up to 12-18 meters
|
|
Alarm Input/ Output
|
1 Channel on/off Input
1 Channel relay Output
|
|
Colour
|
Currently White only
|
|
Dimension
|
105(L) x98(W) x130mm(H)
|
|
Power
|
Power Supply
|
DC 5V/2.0A (EU,US,AU adapter or other types optional)
|
|
Power Consumption
|
7Watts (Max.)
|
|
Environment
|
Operate Temper.
|
-30°C ~ 55°C? (-20°F ~ 131°F)
|
|
Operating? Humidity
|
20% ~ 85% non-condensing
|
|
Storage Temper.
|
-30°C ~60°C
|
|
Storage Humidity
|
0% ~ 90% non-condensing
|
|
PC System Requirements
|
CPU
|
2.0GHZ or above (suggested 3.0GHz)
|
|
Memory Size
|
256MB or above (suggested 1.0GHz)
|
|
Display Card
|
64M or above
|
|
Supported OS
|
Microsoft Windows 2000/XP/7/Vista
|
|
Browser
|
IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers
|
|
Certification
|
CE, FCC, RoHS
|
|
|
Since we only sell new unit, we do not accept any return good unless item found broken upon receive.
All item electronic parts only come with 1 month warranty. Any claim made for warranty, buyer all incurs postages.
